Collimating tool?

[Reggie_Mental]

Anybody ever seen one of these before?



I think it might be a collimating tool to check guns convergance angles. But why not boresight the gun itself?

Even the MotorKanone can boresighted by removing the rear block in the cockpit floorwell

Edited March 7, 2020 by Reggie_Mental

[JaMz]

Hmm, I cannot see how that is being used to check a gun/cannon.. Maybe im wrong but why have an adjustment on the rear?

[Art-J]

Nah, it's just a gun camera by Zeiss, albeit an early and rather bulky one. More photos can be found here:

https://www.thephoblographer.com/2017/12/26/rare-german-gun-camera-wwii/

[Reggie_Mental]

Okay, so it's a gun camera. Odd, I've always thought of these being boxy camera shaped things and certainly not mounted on wings



Or he is just posing for 'Signal', the Nazi erk crab bluffer...

Edited March 7, 2020 by Reggie_Mental

[AndyJWest]

Found this photo of an Me 109 being boresighted (From Wikipedia). Got to be the easiest way, provided the gadget aligns properly.

[Reggie_Mental]

10 hours ago, AndyJWest said:

Found this photo of an Me 109 being boresighted (From Wikipedia). Got to be the easiest way, provided the gadget aligns properly.

Found the same on M4T just a few minutes ago
