a few useful stencils for the Bf109

[Sternjaeger]

interesting little document with some of the most common stencils found on the Bf109G (although some are the same for the F as well), I thought it might be useful for the skinners out there!

Bf-109 Stencils.pdf

Edited December 28, 2013 by Sternjaeger

[Pierre64]

interesting little document with some of the most common stencils found on the Bf109G (although some are the same for the F as well), I thought it might be useful for the skinners out there!

A great "thank you"!

[SOLIDKREATE]

If anyone wants these in a vector format I have a thread on it.



http://forum.il2sturmovik.com/topic/1356-luftwaffe-bf-109-specific-markings/

Edited January 1, 2014 by 9./JG54_SPEKTRE76

[adler_1]

hello

i need bf 109 readable stencils enabling me to type directly on the  2048 HD template . I downloaded all whats here , i need the following :



A) what is written in german below the pilots cockpit hatch or door , they are 2 lines , his side only . i have decal miniatures but i cant read the content .magnifying is worse .

B)  what is written in the stencil above  the rear wheel  .

cheers

Edited November 18, 2017 by dog1

[Pierre64]

Hi dog1,



A)

Beim Schließen der Kabine

auf Vorderteil - Gummirahmen achten!



B)

Reinfendruck 4,5 atū

Edited November 22, 2017 by Pierre64

[adler_1]

thank you very much. do you have an illustrated guide to place all the stencils correctly or a good link  ?

Edited November 27, 2017 by dog1

[adler_1]

what is printed on the wing in red within the red line limit.
