This thread is for all aircraft enthusiasts to post there design ideas for fighters, bombers, attackers, trainers or cargo planes.



Rules:



• Design must be original
• Specifications must use real world parts from the era of 1916-1945
• Do not copy or modify someone elses work.
• No flamming or trolling.
• Do not post images in responses to works submitted by members, only links



That's it lets see what you got.



=======================================================================



Here is my aircraft





Pacific Northwest Aviation, Co.  est 1943



P-73A-10-PN "Peregrine", Fighter Plane,

First flight February 1944, First Combat January 1945, Berlin, PTO March 1945





General characteristics

    Crew: One, pilot
    Length: 25 ft 7 in (8.73 m)
    Wingspan: 28 ft 6 in (9.91 m)
    Height: 12 ft 9 in (4.50 m)
    Wing area: 455 ft² (44.2 m²)
    Empty weight: 9,007 lb (5,958 kg)
    Loaded weight: 11,522 lb (7,600 kg)
    Max. takeoff weight: 18,772 lb (8,533 kg)
    Powerplant: 1 × Pratt & Whitney R-4360-4 - 2,650 hp

Performance

    Maximum speed: 523 mph at 26,000 ft
    Range: 1,064 miles
    Service ceiling: 34,492 ft
    Rate of climb: 3,367 ft/min
    Wing loading: 30 lb/ft²
    Power/mass: 0.22 hp/lb

Armaments

    4 × 20 mm Hispano Mk.II cannons

    or

    8 x 12.7mm M2 Browning machine guns

    or

    2 x × 20 mm Hispano Mk.II cannons and 6 x 12.7mm M2 Browning machine guns



Edited September 14, 2014 by KOTP_SPEKTRE76

[LLv34_Flanker]

S!



 You drew that? Nice one

[SOLIDKREATE]

S!



 You drew that? Nice one





I did with my fancy Papermate M 80% black pen

[6./ZG26_5tuka]

Must have been an aerodynamical nightmare to fly back in 1940s



Nice idea though, maybe I can find the creativity to throw some stuff in (usually drawing real aircraft though nothing too spectacular).

[Schmittfeuer]

Really nice dawing you got there.



I'll put up some of my own stuff now. Some of those planes come from some Crimson Skies inspired alternate history, this mostly means that they have either quite ridiculous engines and weapons, stem from some odd companies or just look weird. Although I believe the ones I picked are some of the less weird ones that fit with the thread. I'll hopefully find the time and motivation to make some proper descriptions for some of these for this thread.



In the meantime enjoy the pictures and give me some of your thoughts on the designs.





Grumman F-83



Basically a reverse Lightning





Messerschmitt-Horten 491



Merging the Go-229 and the Me-262







Something similar in design to the 491 except with canards and a huge cannon







Yet another german jet design







Focke-Wulf/Dornier 626 "Donnerkeil"



A Google Sketchup model I made a while ago. I was aiming for a more fighter-looking Do-335







Focke-Wulf "Silbervogel"



Another Sketchup model, this time however quite a bit more detailed than the Donnerkeil one, it's got a full cockpit interior (although that need revision). It's almost certainly even less aerodynamically sound than all of my other designs (and certainly more suited for the above mentioned CS-inspired setting), but I think it's grown on me because I've tinkered with it for ages.







Edited September 14, 2014 by Schmittfeuer

[Leaf]

I can't draw, but here's my prototype anyway.

The Messerschmidt BF 69 -- catered for the naughty type of pilot:



[Emgy]

Wow, really great drawings! I thought of Crimson Skies too.

Edited September 14, 2014 by Calvamos

[sallee]

I can't draw, but here's my prototype anyway.



The Messerschmidt BF 69 -- catered for the naughty type of pilot:





Do you mind? What if one of my Gee Bees sees that?

[johncage]

if design must be original, i think already failed:



http://en.wikipedia.org/wiki/Vought_V-173

http://en.wikipedia.org/wiki/Vought_XF5U

[SOLIDKREATE]

I love the Do-626 and the F-83!



I'm working on a Naval Attacker right now.
